A type label with information to identify the P2 panel is located at the bottom of the chassis. The following information is printed on the type label:
model number: The model number typically consists of the P2-, 3 digits, and a letter. The model number allows allocation of connection type, stroke length, focus distance and hardware version.
serial number: The serial number typically consists of 6 digits. The serial number is unique for each P2 panel and allows allocation of the built-in components, for example, the mobile unit.
placeholder for MAC address of the P2 panel: The MAC address is the hardware address of the P2 panel, which is used as a unique identifier in networks.
placeholder for bar code
indication of origin
company information
You find the model number, serial number, and MAC address in the web interface of the P2 panel, too.
